| | Node (int classTag) |
| | Default constructor. More...
|
| |
| | Node (int tag, int classTag) |
| | Constructor. More...
|
| |
| | Node (int tag, int ndof, double Crd1) |
| | Constructor. More...
|
| |
| | Node (int tag, int ndof, double Crd1, double Crd2) |
| | Constructor for 2d nodes. More...
|
| |
| | Node (int tag, int ndof, double Crd1, double Crd2, double Crd3) |
| | constructor for 3d nodes More...
|
| |
| | Node (int tag, int ndof, const Vector &crds) |
| | Constructor. More...
|
| |
|
| Node (const Node &theCopy, bool copyMass=true) |
| | used for domain decomposition & external nodes copy everything but the mass we should really set the mass to 0.0
|
| |
|
Node * | getCopy (void) const |
| | Virtual constructor.
|
| |
|
virtual | ~Node (void) |
| | destructor
|
| |
|
virtual int | getNumberDOF (void) const |
| | Return the number of node DOFs.
|
| |
|
virtual void | setDOF_GroupPtr (DOF_Group *theDOF_Grp) |
| | Sets the DOF_Group pointer.
|
| |
|
virtual DOF_Group * | getDOF_GroupPtr (void) |
| | Gets the DOF_Group pointer.
|
| |
|
void | connect (ContinuaReprComponent *el) const |
| | Inserts a component (element, constraint,...) to the connected component list.
|
| |
|
void | disconnect (ContinuaReprComponent *el) const |
| | Removes a component (element, constraint,...) from the connected component list.
|
| |
|
ElementConstPtrSet | getConnectedElements (void) const |
| | Return a list of pointers to the elements that are connected with this node.
|
| |
|
ElementPtrSet | getConnectedElements (void) |
| | Return a list of pointers to the elements that are connected with this node.
|
| |
|
const MeshEdge * | next (const std::deque< MeshEdge > &, const std::set< const MeshEdge * > &) const |
| | Returns an edge that has its origin in this node (and is not in visited).
|
| |
|
const bool | isDead (void) const |
| | True if node is inactive.
|
| |
|
const bool | isAlive (void) const |
| | True if node is active.
|
| |
|
const bool | isFrozen (void) const |
| | returns true if the node is frozen.
|
| |
|
const bool | isFree (void) const |
| | returns true if the node has no constraints.
|
| |
|
void | kill (void) |
| |
|
void | alive (void) |
| |
|
void | freeze_if_dead (NodeLocker *locker) |
| | Imposes zero displacement (zero value for all node DOFs).
|
| |
|
void | melt_if_alive (NodeLocker *locker) |
| | Deletes the constraint over the node DOFs previously created by the freeze method.
|
| |
|
SFreedom_Constraint * | fix (const SFreedom_Constraint &) |
| | Introduce en el nodo una constraint como la being passed as parameter.
|
| |
|
void | fix (const std::vector< int > &, const std::vector< double > &) |
| | Sets prescribed displacements on the DOFs being passed as parameter.
|
| |
|
void | fix (const ID &, const Vector &) |
| | Sets prescribed displacements on the DOFs being passed as parameter.
|
| |
|
virtual size_t | getDim (void) const |
| | Return the dimension of the node vector position (1,2 or 3).
|
| |
|
virtual const Vector & | getCrds (void) const |
| | return the vector of nodal coordinates
|
| |
|
virtual Vector & | getCrds (void) |
| | return the vector of nodal coordinates
|
| |
|
Vector | getCrds3d (void) const |
| | Returns the coordenadas del nodo en un espacio 3d.
|
| |
|
Pos2d | getPosInicial2d (void) const |
| | Return the intial position of the node in 2D.
|
| |
|
Pos3d | getPosInicial3d (void) const |
| | Return the intial position of the node in 3D.
|
| |
|
Pos2d | getPosFinal2d (void) const |
| | Return the final position of the node.
|
| |
|
Pos3d | getPosFinal3d (void) const |
| | Return the final position of the node.
|
| |
|
void | setPos (const Pos3d &) |
| | Sets the node position.
|
| |
|
void | Mueve (const Vector3d &desplaz) |
| | Moves the node (intended only for its use from XC::Set).
|
| |
|
void | Transforma (const TrfGeom &trf) |
| | Applies to the node position the transformation being passed as parameter.
|
| |
| double | getDist2 (const Pos2d &p, bool initialGeometry=true) const |
| | Returns the square of the distance from the node to the point being passed as parameter. More...
|
| |
| double | getDist (const Pos2d &p, bool initialGeometry=true) const |
| | Returns the distance from the node to the point being passed as parameter. More...
|
| |
| double | getDist2 (const Pos3d &p, bool initialGeometry=true) const |
| | Returns the square of the distance from the node to the point being passed as parameter. More...
|
| |
| double | getDist (const Pos3d &p, bool initialGeometry=true) const |
| | Returns the distance from the node to the point being passed as parameter. More...
|
| |
|
virtual const Vector & | getDisp (void) const |
| | Returns the displacement of the node.
|
| |
|
Vector | getDispXYZ (void) const |
| | Returns the XYZ components of node displacement.
|
| |
|
Vector | getRotXYZ (void) const |
| | Returns the XYZ components of node rotation.
|
| |
|
virtual const Vector & | getVel (void) const |
| | Returns the velocity of the node.
|
| |
|
Vector | getVelXYZ (void) const |
| | Returns the XYZ components of the translational velocity of the node.
|
| |
|
Vector | getOmegaXYZ (void) const |
| | Returns the XYZ components of the angular velocity of the node.
|
| |
|
virtual const Vector & | getAccel (void) const |
| | Returns the acceleration of the node.
|
| |
|
Vector | getAccelXYZ (void) const |
| | Returns the XYZ components of the translational acceleration of the node.
|
| |
|
Vector | getAlphaXYZ (void) const |
| | Returns the XYZ components of the angular acceleration of the node.
|
| |
|
virtual const Vector & | getIncrDisp (void) const |
| | Returns the displacement increment.
|
| |
|
virtual const Vector & | getIncrDeltaDisp (void) const |
| |
|
virtual const Vector & | getTrialDisp (void) const |
| | Returns the trial value of the displacement of the node.
|
| |
|
virtual const Vector & | getTrialVel (void) const |
| | Returns the trial value of the velocity of the node.
|
| |
|
virtual const Vector & | getTrialAccel (void) const |
| | Returns the trial value of the acceleration of the node.
|
| |
|
virtual int | setTrialDispComponent (double value, int dof) |
| |
|
virtual int | setTrialDisp (const Vector &) |
| |
|
virtual int | setTrialVel (const Vector &) |
| |
|
virtual int | setTrialAccel (const Vector &) |
| |
|
virtual int | incrTrialDisp (const Vector &) |
| |
|
virtual int | incrTrialVel (const Vector &) |
| |
|
virtual int | incrTrialAccel (const Vector &) |
| |
|
virtual void | zeroUnbalancedLoad (void) |
| |
| virtual int | addUnbalancedLoad (const Vector &load, double fact=1.0) |
| | Adds vector to unbalanced load. More...
|
| |
|
virtual int | addInertiaLoadToUnbalance (const Vector &accel, double fact=1.0) |
| | Adds inertial loads to unbalanced load vector.
|
| |
|
virtual const Vector & | getUnbalancedLoad (void) |
| | Returns unbalanced load vector.
|
| |
|
virtual const Vector & | getUnbalancedLoadIncInertia (void) |
| | Return unbalanced load vector including inertial forces.
|
| |
|
virtual int | commitState () |
| | Commits the state of the node.
|
| |
|
virtual int | revertToLastCommit () |
| | Returns to the last commited state.
|
| |
|
virtual int | revertToStart () |
| | Returns to the initial state.
|
| |
|
virtual const Matrix & | getMass (void) |
| | Return the matriz de masas del nodo.
|
| |
|
virtual int | setMass (const Matrix &theMass) |
| | Asigna la matriz de masas to the node.
|
| |
|
virtual int | setNumColR (int numCol) |
| |
|
virtual int | setR (int row, int col, double Value) |
| |
|
virtual const Vector & | getRV (const Vector &V) |
| |
|
virtual int | setRayleighDampingFactor (double alphaM) |
| | Returns the coeficiente de amortiguamiento de Rayleigh.
|
| |
|
virtual const Matrix & | getDamp (void) |
| | Return the matriz de amortiguamiento del nodo.
|
| |
|
void | addTributaria (const double &) const |
| | Adds to the magnitud tributaria la longitud, área o volumen being passed as parameter.
|
| |
|
void | resetTributaria (void) const |
| | Anula la magnitud tributaria (longitud, área o volumen).
|
| |
|
const double & | getTributaria (void) const |
| | Return the magnitud tributaria (longitud, área o volumen).
|
| |
|
virtual int | setNumEigenvectors (int numVectorsToStore) |
| | Dimensiona la matriz que contiene a los eigenvectors.
|
| |
|
virtual int | setEigenvector (int mode, const Vector &eigenVector) |
| | Asigna el autovector eigenvector al modo mode.
|
| |
|
int | getNumModes (void) const |
| |
|
virtual Vector | getEigenvector (int mode) const |
| | Returns the autovector correspondiente al modo i.
|
| |
|
Vector | getNormalizedEigenvector (int mode) const |
| | Returns the autovector correspondiente al modo i normalizado de modo que la componente máxima valga 1 (norma_infinito).
|
| |
|
virtual const Matrix & | getEigenvectors (void) |
| | Returns the eigenvectors correspondientes to the node.
|
| |
|
Matrix | getNormalizedEigenvectors (void) const |
| | Returns a matriz con los eigenvectors normalizados colocados por columnas (norma_infinito).
|
| |
|
double | getAngularFrequency (int) const |
| | Return the angular frequency corresponding to the i-th mode.
|
| |
|
Vector | getAngularFrequencies (void) const |
| | Returns the angular frequencies from the modal analysis.
|
| |
|
virtual double | getModalParticipationFactor (int mode) const |
| | Returns the modal participation factor corresponding to i-th mode.
|
| |
|
Vector | getModalParticipationFactors (void) const |
| | Returns the modal participation factors.
|
| |
| virtual double | getModalParticipationFactor (int mode, const std::set< int > &gdls) const |
| | Returns the modal participation factor corresponding to i-th mode. If the gdls argument is not empty it "projects" the i-th mode over the selected DOFs in the argument. It's written to allow expressing the participation with respect to a DOF (see verification test: test_cqc_01.xc). THE RESULTS OF THIS FUNCTION DOESN'T MATCH WITH THOSE OBTAINED FROM THE EIGENVALUE PROBLEM. More...
|
| |
| Vector | getModalParticipationFactors (const std::set< int > &gdls) const |
| | Returns the modal participation factors. If gdls argument is not empty it "projects" the i-th mode over the selected DOFs in the argument. More...
|
| |
| Vector | getModalParticipationFactorsForGdls (const boost::python::list &) const |
| | Returns the modal participation factors. If gdls argument is not empty it "projects" the i-th mode over the selected DOFs in the argument. More...
|
| |
|
Vector | getDistributionFactor (int mode) const |
| | Returns the distribution factor of the i-th mode.
|
| |
| Vector | getDistributionFactor (int mode, const std::set< int > &gdls) const |
| | Returns the distribution factor corresponding to the mode being passed as parameter. If gdls argument is not it "projects" the i-th mode over the selected DOFs in the argument. More...
|
| |
|
Matrix | getDistributionFactors (void) const |
| | Returns the matrix with the computed distribution factors placed by columns.
|
| |
|
double | getEffectiveModalMass (int mode) const |
| | Return the masa modal efectiva correspondiente al modo i.
|
| |
|
Vector | getEffectiveModalMasses (void) const |
| | Returns the effective modal mases.
|
| |
|
Vector | getEquivalentStaticLoad (int mode, const double &) const |
| | Return the equivalent static load for the mode being passed as parameter and the acceleration corresponding to that mode.
|
| |
|
Vector | getMaxModalDisplacement (int mode, const double &) const |
| | Returns the maximal modal displacement for the node being passed as parameter and the acceleration corresponding to that mode.
|
| |
|
Vector | getMaxModalVelocity (int mode, const double &) const |
| | Return the maximal modal velocity for the mode being passed as parameter and the acceleration corresponding to that mode.
|
| |
|
Vector | getMaxModalAcceleration (int mode, const double &) const |
| | Return the maximal modal acceleration for the mode being passed as parameter and the acceleration corresponding to that mode.
|
| |
| Vector | getMaxModalDisplacementForGdls (int mode, const double &, const std::set< int > &gdls) const |
| | Returns the maximal modal displacement on the DOFs and mode being passed as parameter and the acceleration corresponding to that mode. More...
|
| |
| Vector | getMaxModalVelocityForGdls (int mode, const double &, const std::set< int > &gdls) const |
| | Returns the maximum modal velocity on the DOFs and mode being passed as parameter and the acceleration corresponding to that mode. More...
|
| |
| Vector | getMaxModalAccelerationForGdls (int mode, const double &, const std::set< int > &gdls) const |
| | Return the maximal modal acceleration on the DOFs and mode being passed as parameter and the acceleration corresponding to that mode. More...
|
| |
| Vector | getMaxModalDisplacementForGdls (int mode, const double &, const boost::python::list &gdls) const |
| | Returns the maximal modal displacement on the DOFs and mode being passed as parameter and the acceleration corresponding to that mode. More...
|
| |
| Vector | getMaxModalVelocityForGdls (int mode, const double &, const boost::python::list &gdls) const |
| | Returns the maximum modal velocity on the DOFs and mode being passed as parameter and the acceleration corresponding to that mode. More...
|
| |
| Vector | getMaxModalAccelerationForGdls (int mode, const double &, const boost::python::list &gdls) const |
| | Return the maximal modal acceleration on the DOFs and mode being passed as parameter and the acceleration corresponding to that mode. More...
|
| |
|
virtual int | sendSelf (CommParameters &) |
| | Envia el objeto through the channel being passed as parameter.
|
| |
|
virtual int | recvSelf (const CommParameters &) |
| | Receives object through the channel being passed as parameter.
|
| |
|
std::set< SetBase * > | get_sets (void) const |
| | Returns the sets a los que pertenece este nodo.
|
| |
|
void | add_to_sets (std::set< SetBase * > &) |
| | Adds the node to the sets being passed as parameters.
|
| |
|
virtual void | Print (std::ostream &s, int flag=0) |
| | Imprime el objeto.
|
| |
|
virtual const Vector & | getReaction (void) const |
| | Return the node reaction.
|
| |
|
const Vector & | getResistingForce (const ElementConstPtrSet &, const bool &) const |
| | Return the action of the elements from the set over this node.
|
| |
|
SVD3d | getResistingSVD3d (const ElementConstPtrSet &, const bool &) const |
| | Returns the sliding vector system that represents the action of the elements of the set over the node.
|
| |
|
virtual int | addReactionForce (const Vector &, double factor) |
| | Increments the node reaction.
|
| |
|
virtual int | resetReactionForce (bool inclInertia) |
| | Calculate the reactions in this node (used in en Domain::calculateNodalReactions).
|
| |
|
void | checkReactionForce (const double &) |
| | Checks reaction on the node.
|
| |
|
int | addInertiaLoadSensitivityToUnbalance (const Vector &accel, double fact=1.0, bool tag=false) |
| |
|
Matrix | getMassSensitivity (void) |
| |
|
virtual const Matrix & | getDampSensitivity (void) |
| |
|
int | getCrdsSensitivity (void) |
| |
|
int | saveSensitivity (Vector *v, Vector *vdot, Vector *vdotdot, int gradNum, int numGrads) |
| |
|
double | getDispSensitivity (int dof, int gradNum) |
| |
|
double | getVelSensitivity (int dof, int gradNum) |
| |
|
double | getAccSensitivity (int dof, int gradNum) |
| |
|
int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| |
|
int | updateParameter (int parameterID, Information &info) |
| |
|
int | activateParameter (int parameterID) |
| |
|
| MeshComponent (int classTag) |
| | Constructor.
|
| |
|
| MeshComponent (int tag, int classTag) |
| | Constructor.
|
| |
|
| ContinuaReprComponent (int classTag) |
| |
|
| ContinuaReprComponent (int tag, int classTag) |
| |
 Public Member Functions inherited from XC::DomainComponent |
|
| ~DomainComponent (void) |
| | Destructor.
|
| |
|
size_t | getIdx (void) const |
| | Returns the index of the object (to be used in VTK arrays).
|
| |
|
virtual void | setDomain (Domain *theDomain) |
| | Asigna a pointer al domain.
|
| |
|
virtual Domain * | getDomain (void) const |
| | Returns a pointer to the domain.
|
| |
|
const Preprocessor * | GetPreprocessor (void) const |
| | Returns (if possible) a pointer to the preprocessor.
|
| |
|
Preprocessor * | GetPreprocessor (void) |
| | Returns (if possible) a pointer to the preprocessor.
|
| |
|
void | set_indice (const size_t &i) |
| | Set the index for the object (see numera in Set). This index is used on VTK arrays.
|
| |
|
| TaggedObject (int tag, EntCmd *owr=nullptr) |
| | Constructor.
|
| |
|
void | assignTag (int newTag) |
| | Establece el valor del tag.
|
| |
|
int | getTag (void) const |
| |
|
| MovableObject (int classTag, int dbTag) |
| | Constructor.
|
| |
|
| MovableObject (int classTag) |
| | Constructor.
|
| |
|
| MovableObject (const MovableObject &otro) |
| | Copy constructor.
|
| |
|
MovableObject & | operator= (const MovableObject &otro) |
| | Operacdor asignación.
|
| |
|
int | getClassTag (void) const |
| | Returns the tag de la clase.
|
| |
|
int | getDbTag (void) const |
| | Returns the tag para la database.
|
| |
|
int | getDbTag (CommParameters &) |
| | Returns the tag para la database.
|
| |
|
void | setDbTag (int dbTag) |
| | Asigna el tag para la database.
|
| |
|
void | setDbTag (CommParameters &) |
| | Asigna, sólo si es preciso, el tag para la database.
|
| |
|
virtual int | setVariable (const std::string &variable, Information &) |
| | Returns the identificador de la variable cuyo nombre being passed as parameter.
|
| |
|
virtual int | getVariable (const std::string &variable, Information &) |
| |
|
| DistributedBase (void) |
| | Constructor.
|
| |
|
const int & | getDbTagDataPos (const int &i) const |
| | Returns the data at the i-th position.
|
| |
|
void | setDbTagDataPos (const int &i, const int &v) |
| | Sets the data at the i-th position.
|
| |
|
void | inicComm (const int &dataSize) const |
| | Initializes communication.
|
| |
1.8.11
