XC Open source finite element analysis program
|
Imposes a rigid body motion to the nodes on included in the diaphragm . More...
#include <RigidDiaphragm.h>
Public Member Functions | |
| RigidDiaphragm (Domain &theDomain, int nodeR, ID &nodeC, int perpDirnToPlaneConstrained, int startMPtag) | |
| Constructor. More... | |
| virtual | ~RigidDiaphragm () |
| Destructor. | |
 Public Member Functions inherited from XC::MFreedom_Constraint | |
| MFreedom_Constraint (int tag, int classTag) | |
| ! More... | |
| MFreedom_Constraint (int tag) | |
| Constructor. // LCPT. | |
| MFreedom_Constraint (int tag, int nodeRetain, int nodeConstr, int classTag) | |
| MFreedom_Constraint (int tag, int nodeRetain, int nodeConstr, const ID &constrainedDOF, const ID &retainedDOF) | |
| MFreedom_Constraint (int tag, int nodeRetain, int nodeConstr, const ID &constrainedDOF, const ID &retainedDOF, int classTag) | |
| MFreedom_Constraint (int tag, int nodeRetain, int nodeConstr, Matrix &constrnt, ID &constrainedDOF, ID &retainedDOF) | |
| Constructor. More... | |
| virtual const int & | getNodeRetained (void) const |
| Returns the tag of the retained (or master) node. | |
| virtual int & | getNodeRetained (void) |
| Returns the tag of the retained (or master) node. | |
| virtual size_t | getNumRetainedNodes (void) const |
| Returns the number of retained nodes. | |
| std::vector< XC::Node * > | getPointersToRetainedNodes (void) const |
| Returns a vector with the pointers to the retained nodes. | |
| bool | affectsNode (int) const |
| Returns true ifafecta to the node cuyo tag being passed as parameter. | |
| virtual const ID & | getRetainedDOFs (void) const |
| Returns the identifiers of the retained degrees of freedom. | |
| virtual int | applyConstraint (double pseudoTime) |
| Applies the constraint at the pseudo-time being passed as parameter. | |
| virtual int | sendSelf (CommParameters &) |
| Sends object through the channel being passed as parameter. | |
| virtual int | recvSelf (const CommParameters &) |
| Receives object through the channel being passed as parameter. | |
| int | getVtkCellType (void) const |
| Interfaz con VTK. | |
| int | getMEDCellType (void) const |
| Interface with Salome MED format. | |
| virtual void | Print (std::ostream &s, int flag=0) |
| Printing. | |
| Public Member Functions inherited from XC::MFreedom_ConstraintBase | |
| MFreedom_ConstraintBase (int tag, int classTag) | |
| Constructor. More... | |
| MFreedom_ConstraintBase (int tag, int nodeConstr, int classTag) | |
| Constructor to be called from subclasses. More... | |
| MFreedom_ConstraintBase (int tag, int nodeConstr, const ID &, int classTag) | |
| Constructor to be called from subclasses. More... | |
| MFreedom_ConstraintBase (int tag, int nodeConstr, const Matrix &, const ID &, int classTag) | |
| Constructor. More... | |
| virtual const int & | getNodeConstrained (void) const |
| virtual int & | getNodeConstrained (void) |
| bool | affectsNode (int) const |
| Returns true if the constraints affects the node identified by the tag being passed as parameter. | |
| virtual const ID & | getConstrainedDOFs (void) const |
| Returns the identifiers of the constrained degrees of fredom. | |
| virtual const Matrix & | getConstraint (void) const |
| Returns the constraint matrix. | |
| bool | isTimeVarying (void) const |
| Returns true if the constraint varies with time. | |
| int | addResistingForceToNodalReaction (bool inclInertia) |
| Add reactions to nodes. | |
| Public Member Functions inherited from XC::Constraint | |
| Constraint (int classTag) | |
| Default constructor; receives the tag of the class as a paramenter. More... | |
| Constraint (int spTag, int nodeTag, int classTag) | |
| Constructor. More... | |
| ~Constraint (void) | |
| Destructor. | |
| void | setNodeTag (const int &nt) |
| Sets the identifier of the node that will be constrained. More... | |
| virtual int | getNodeTag (void) const |
| Returns the identifier of the constrained node. | |
| virtual const Node * | getNode (void) const |
| Returns a pointer to the constrained node. | |
| virtual int | getNodeIdx (void) const |
| Returns an index for the node (used for VTK arrays). | |
| void | setDomain (Domain *) |
| Sets the domain for the constraint. More... | |
| Public Member Functions inherited from XC::ContinuaReprComponent | |
| ContinuaReprComponent (int classTag) | |
| ContinuaReprComponent (int tag, int classTag) | |
| virtual const bool | isDead (void) const |
| virtual const bool | isAlive (void) const |
| virtual void | kill (void) |
| virtual void | alive (void) |
| Public Member Functions inherited from XC::DomainComponent | |
| ~DomainComponent (void) | |
| Destructor. | |
| size_t | getIdx (void) const |
| Returns the index of the object (to be used in VTK arrays). | |
| virtual Domain * | getDomain (void) const |
| Returns a pointer to the domain. | |
| const Preprocessor * | GetPreprocessor (void) const |
| Returns (if possible) a pointer to the preprocessor. | |
| Preprocessor * | GetPreprocessor (void) |
| Returns (if possible) a pointer to the preprocessor. | |
| void | set_indice (const size_t &i) |
| Set the index for the object (see numera in Set). This index is used on VTK arrays. | |
| Public Member Functions inherited from XC::TaggedObject | |
| TaggedObject (int tag, EntCmd *owr=nullptr) | |
| Constructor. | |
| virtual TaggedObject * | getCopy (void) const |
| Virtual constructor. | |
| void | assignTag (int newTag) |
| Establece el valor del tag. | |
| int | getTag (void) const |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Additional Inherited Members | |
| Protected Member Functions inherited from XC::MFreedom_Constraint | |
| void | set_retained_dofs (const ID &) |
| Sets the retained degrees of freedom. | |
| void | set_constrained_retained_dofs (const ID &constrainedDOF, const ID &retainedDOF) |
| Sets the retained and constrained degrees of freedom. | |
| int | sendData (CommParameters &cp) |
| Sends data through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receives data through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::MFreedom_ConstraintBase | |
| void | set_constraint (const Matrix &c) |
| Set the constraint matrix. | |
| void | set_constrained_dofs (const ID &) |
| Set the constrained degrees of freedom. More... | |
| int | sendData (CommParameters &cp) |
| Send data through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receive data through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::Constraint | |
| int | sendData (CommParameters &) |
| Send members through the channel being passed as parameter. More... | |
| int | recvData (const CommParameters &) |
| Receives members through the channel being passed as parameter. More... | |
| Protected Member Functions inherited from XC::ContinuaReprComponent | |
| int | sendData (CommParameters &) |
| Send members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receives members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::DomainComponent | |
| DomainComponent (int tag, int classTag) | |
| Constructor. | |
| int | sendData (CommParameters &) |
| Send object members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receives object members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::TaggedObject | |
| void | setTag (int newTag) |
| Establece el valor del tag. | |
| Protected Attributes inherited from XC::MFreedom_Constraint | |
| int | retainedNodeTag |
| Tag of the retained node. | |
| ID | retainDOF |
| ID of retained DOF at retained node. | |
| Protected Attributes inherited from XC::MFreedom_ConstraintBase | |
| Matrix | constraintMatrix |
| Constraint matrix. | |
| ID | constrDOF |
| ID of constrained DOF at constrained node. | |
| Protected Attributes inherited from XC::Constraint | |
| int | constrNodeTag |
| constrained node tag | |
Imposes a rigid body motion to the nodes on included in the diaphragm .
| XC::RigidDiaphragm::RigidDiaphragm | ( | Domain & | theDomain, |
| int | nR, | ||
| ID & | nC, | ||
| int | perpPlaneConstrained, | ||
| int | startMPtag | ||
| ) |
Constructor.
| theDomain | domain where the constraint is defined. |
| nR | identifier of the retained node. |
| nC | identifiers of the constrained nodes. |
| perpPlaneConstrained | direction of perpendicular to constained plane: 0, 1 or 3. |
| startMPtag | tag for the first multi-freedom constraint (one constraint for each node). |
