XC Open source finite element analysis program
|
PenaltyConstraintHandler is a constraint handler deals with both single and multi point constraints using the penalty method. for each element and degree-of-freedom at a node it constructs regular FE_Element and DOF_Groups; for each SFreedom_Constraint and MFreedom_Constraint PenaltySFreedom_FE and PenaltyMFreedom_FE elements are created. More...
#include <PenaltyConstraintHandler.h>
Public Member Functions | |
| int | handle (const ID *nodesNumberedLast=0) |
| Handle the constraints. | |
 Public Member Functions inherited from XC::FactorsConstraintHandler | |
| void | setAlphaSP (const double &a) |
| Set the factor used with single freedom constraints. | |
| double | getAlphaSP (void) const |
| Return the factor used with single freedom constraints. | |
| void | setAlphaMP (const double &a) |
| Set the factor used with multi-freedom constraints. | |
| double | getAlphaMP (void) const |
| Return the factor used with multi-freedom constraints. | |
| virtual int | sendSelf (CommParameters &) |
| Send object through the channel passed as parameter. | |
| virtual int | recvSelf (const CommParameters &) |
| Receive object through the channel passed as parameter. | |
| Public Member Functions inherited from XC::ConstraintHandler | |
| virtual int | update (void) |
| Update the state of the constraints. | |
| virtual int | applyLoad (void) |
| ?? | |
| virtual int | doneNumberingDOF (void) |
| Numbering of degrees of freedom. | |
| virtual void | clearAll (void) |
| Reset the DOF_Group pointers to nullptr for all the nodes. | |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Friends | |
| class | ModelWrapper |
| class | FEM_ObjectBroker |
Additional Inherited Members | |
| Protected Member Functions inherited from XC::FactorsConstraintHandler | |
| int | sendData (CommParameters &) |
| Send object members through the channel passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receive object members through the channel passed as parameter. | |
| FactorsConstraintHandler (ModelWrapper *, int classTag, const double &alphaSP, const double &alphaMP) | |
| Constructor. More... | |
| Protected Member Functions inherited from XC::ConstraintHandler | |
| const Domain * | getDomainPtr (void) const |
| Return a const pointer to the domain object associated with the ConstraintHandler. | |
| const AnalysisModel * | getAnalysisModelPtr (void) const |
| Return a const pointer to the analysis model object associated with the ConstraintHandler. | |
| const Integrator * | getIntegratorPtr (void) const |
| Return a pointer to the Integrator object associated with the ConstraintHandler. | |
| Domain * | getDomainPtr (void) |
| Return a pointer to the Domain object associated with the ConstraintHandler. | |
| AnalysisModel * | getAnalysisModelPtr (void) |
| Returns a pointer to the AnalysisModel object associated with the ConstraintHandler. | |
| Integrator * | getIntegratorPtr (void) |
| Returns a pointer to the Integrator object associated with the ConstraintHandler. | |
| int | sendData (CommParameters &) |
| Send object members through the channel passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receive object members through the channel passed as parameter. | |
| ConstraintHandler (ModelWrapper *, int classTag) | |
| Constructor. More... | |
| Protected Attributes inherited from XC::FactorsConstraintHandler | |
| double | alphaSP |
| Factor used with the single freedom constraints. | |
| double | alphaMP |
| Factor used with the multi-freedom constraints. | |
PenaltyConstraintHandler is a constraint handler deals with both single and multi point constraints using the penalty method. for each element and degree-of-freedom at a node it constructs regular FE_Element and DOF_Groups; for each SFreedom_Constraint and MFreedom_Constraint PenaltySFreedom_FE and PenaltyMFreedom_FE elements are created.
