Prescribed value over a single degree of freedom. More...
#include <ImposedMotionSP1.h>
Public Member Functions | |
| ImposedMotionSP1 (void) | |
| constructor for FEM_ObjectBroker | |
| ImposedMotionSP1 (int spTag, int nodeTag, int ndof, int patternTag, int groundMotionTag) | |
| constructor for a subclass to use | |
| int | applyConstraint (double loadFactor) |
| Applies constraint at the pseudo-time being passed as parameter. | |
| bool | isHomogeneous (void) const |
| Returns true if it's an homogeneous constraint (prescribed value for the DOF is zero). | |
| int | sendSelf (CommParameters &) |
| Sends object through the channel being passed as parameter. | |
| int | recvSelf (const CommParameters &) |
| Receives object through the channel being passed as parameter. | |
| void | Print (std::ostream &s, int flag=0) |
| Printing. | |
 Public Member Functions inherited from XC::ImposedMotionBase | |
| ImposedMotionBase (int classTag) | |
| Constructor. More... | |
| ImposedMotionBase (int classTag, int spTag, int nodeTag, int ndof, int patternTag, int theGroundMotionTag) | |
| Constructor. More... | |
| ~ImposedMotionBase (void) | |
| Destructor. | |
| void | setDomain (Domain *theDomain) |
| Sets the domain of the constraint. | |
| double | getValue (void) const |
| Returns the prescribed value. | |
| int | getMotion (void) |
| Gets the constraint motion. | |
| int | sendData (CommParameters &cp) |
| Sends object members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receives object through the channel being passed as parameter. | |
| Public Member Functions inherited from XC::SFreedom_Constraint | |
| SFreedom_Constraint (int classTag) | |
| Default constructor. | |
| SFreedom_Constraint (int spTag, int nodeTag) | |
| Constructor. More... | |
| SFreedom_Constraint (int spTag, int nodeTag, int ndof, int classTag) | |
| Constructor. More... | |
| SFreedom_Constraint (int spTag, int nodeTag, int ndof, double value, bool isConstant=true) | |
| Constructor. More... | |
| virtual SFreedom_Constraint * | getCopy (void) const |
| Virtual constructor. | |
| SFreedom_Constraint * | getCopy (const int &) const |
| Returns a copy of the contraint with a different tag, it's used in ConstraintLoader::addSFreedom_Constraint(nodeTag,seed). | |
| virtual int | getDOF_Number (void) const |
| Returns the constrained DOF number. | |
| virtual void | setLoadPatternTag (int loadPaternTag) |
| Sets the load pattern tag for the constraint. More... | |
| virtual int | getLoadPatternTag (void) const |
| Returns the load pattern tag of the constraint. More... | |
| int | getVtkCellType (void) const |
| Returns the cell type to be used to represent the object in VTK graphics. | |
| int | sendSelf (CommParameters &) |
| Sends object through the channel being passed as parameter. | |
| int | recvSelf (const CommParameters &) |
| Receives object through the channel being passed as parameter. | |
| Public Member Functions inherited from XC::Constraint | |
| Constraint (int classTag) | |
| Default constructor; receives the tag of the class as a paramenter. More... | |
| Constraint (int spTag, int nodeTag, int classTag) | |
| Constructor. More... | |
| ~Constraint (void) | |
| Destructor. | |
| void | setNodeTag (const int &nt) |
| Sets the identifier of the node that will be constrained. More... | |
| virtual int | getNodeTag (void) const |
| Returns the identifier of the constrained node. | |
| virtual const Node * | getNode (void) const |
| Returns a pointer to the constrained node. | |
| virtual int | getNodeIdx (void) const |
| Returns an index for the node (used for VTK arrays). | |
| virtual int | getMEDCellType (void) const |
| returns the "MED fichier" cell type. | |
| Public Member Functions inherited from XC::ContinuaReprComponent | |
| ContinuaReprComponent (int classTag) | |
| ContinuaReprComponent (int tag, int classTag) | |
| virtual const bool | isDead (void) const |
| virtual const bool | isAlive (void) const |
| virtual void | kill (void) |
| virtual void | alive (void) |
| Public Member Functions inherited from XC::DomainComponent | |
| ~DomainComponent (void) | |
| Destructor. | |
| size_t | getIdx (void) const |
| Returns the index of the object (to be used in VTK arrays). | |
| virtual Domain * | getDomain (void) const |
| Returns a pointer to the domain. | |
| const Preprocessor * | GetPreprocessor (void) const |
| Returns (if possible) a pointer to the preprocessor. | |
| Preprocessor * | GetPreprocessor (void) |
| Returns (if possible) a pointer to the preprocessor. | |
| void | set_indice (const size_t &i) |
| Set the index for the object (see numera in Set). This index is used on VTK arrays. | |
| Public Member Functions inherited from XC::TaggedObject | |
| TaggedObject (int tag, EntCmd *owr=nullptr) | |
| Constructor. | |
| void | assignTag (int newTag) |
| Establece el valor del tag. | |
| int | getTag (void) const |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Protected Member Functions | |
| int | sendData (CommParameters &cp) |
| Send object members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receives object members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::SFreedom_Constraint | |
| DbTagData & | getDbTagData (void) const |
| Returns a vector para almacenar los dbTags de los miembros de la clase. | |
| int | sendData (CommParameters &cp) |
| Sends data through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receives data through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::Constraint | |
| int | sendData (CommParameters &) |
| Send members through the channel being passed as parameter. More... | |
| int | recvData (const CommParameters &) |
| Receives members through the channel being passed as parameter. More... | |
| Protected Member Functions inherited from XC::ContinuaReprComponent | |
| int | sendData (CommParameters &) |
| Send members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receives members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::DomainComponent | |
| DomainComponent (int tag, int classTag) | |
| Constructor. | |
| int | sendData (CommParameters &) |
| Send object members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receives object members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::TaggedObject | |
| void | setTag (int newTag) |
| Establece el valor del tag. | |
Additional Inherited Members | |
| Protected Attributes inherited from XC::ImposedMotionBase | |
| GroundMotion * | theGroundMotion |
| Node * | theNode |
| pointer to node being constrained | |
| Vector | theGroundMotionResponse |
| Protected Attributes inherited from XC::SFreedom_Constraint | |
| int | dofNumber |
| identifies which of the nodes dof is constrained | |
| double | valueR |
| the reference value | |
| double | valueC |
| if constant = the reference value, if not constant = the reference value * load factor | |
| bool | isConstant |
| flag indicating if constant | |
| int | loadPatternTag |
| Protected Attributes inherited from XC::Constraint | |
| int | constrNodeTag |
| constrained node tag | |
Prescribed value over a single degree of freedom.
