XC Open source finite element analysis program
|
A EnvelopeRecorder is used to record the envelop of specified DOF responses at a collection of nodes over an analysis. (between commitTag of 0 and last commitTag). More...
#include <EnvelopeNodeRecorder.h>
Public Member Functions | |
| EnvelopeNodeRecorder (const ID &theDof, const ID &theNodes, const char *dataToStore, Domain &theDomain, DataOutputHandler &theOutputHandler, double deltaT=0.0, bool echoTimeFlag=false) | |
| int | record (int commitTag, double timeStamp) |
| int | restart (void) |
| int | sendSelf (CommParameters &) |
| Envía el objeto a través del comunicador que being passed as parameter. | |
| int | recvSelf (const CommParameters &) |
| Recibe el objeto a través del comunicador que being passed as parameter. | |
 Public Member Functions inherited from XC::NodeRecorderBase | |
| NodeRecorderBase (int classTag) | |
| NodeRecorderBase (int classTag, const ID &theDof, const ID &theNodes, Domain &theDomain, DataOutputHandler &theOutputHandler, double deltaT=0.0, bool echoTimeFlag=true) | |
| Public Member Functions inherited from XC::MeshCompRecorder | |
| MeshCompRecorder (int classTag) | |
| MeshCompRecorder (int classTag, Domain &theDomain, DataOutputHandler &theOutputHandler, double deltaT=0.0, bool echoTimeFlag=true) | |
| Public Member Functions inherited from XC::HandlerRecorder | |
| HandlerRecorder (int classTag) | |
| HandlerRecorder (int classTag, Domain &theDomain, DataOutputHandler &theOutputHandler, bool timeFlag) | |
| void | SetOutputHandler (DataOutputHandler *tH) |
| Sets de data output handler. | |
| Public Member Functions inherited from XC::DomainRecorderBase | |
| DomainRecorderBase (int classTag, Domain *ptr_dom=nullptr) | |
| int | setDomain (Domain &theDomain) |
| Public Member Functions inherited from XC::Recorder | |
| Recorder (int classTag) | |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Protected Member Functions | |
| int | sendData (CommParameters &) |
| Envía el objeto a través del comunicador que being passed as parameter. | |
| int | receiveData (const CommParameters &) |
| Recibe el objeto a través del comunicador que being passed as parameter. | |
| Protected Member Functions inherited from XC::NodeRecorderBase | |
| int | sendData (CommParameters &) |
| Envía el objeto a través del comunicador que being passed as parameter. | |
| int | receiveData (const CommParameters &) |
| Recibe el objeto a través del comunicador que being passed as parameter. | |
| Protected Member Functions inherited from XC::MeshCompRecorder | |
| int | sendData (CommParameters &) |
| Envia el objeto mediante el comunicador being passed as parameter. | |
| int | receiveData (const CommParameters &) |
| Receives object through the communicator being passed as parameter. | |
| Protected Member Functions inherited from XC::HandlerRecorder | |
| int | sendData (CommParameters &) |
| Sends objet through the communicator being passed as parameter. | |
| int | receiveData (const CommParameters &) |
| Receives objet through the communicator being passed as parameter. | |
Additional Inherited Members | |
| Protected Attributes inherited from XC::NodeRecorderBase | |
| ID * | theDofs |
| DOFs identifiers. | |
| ID * | theNodalTags |
| ?? | |
| std::vector< Node * > | theNodes |
| Pointer to nodes. | |
| int | dataFlag |
| flag indicating what it is to be stored in recorder. | |
| int | numValidNodes |
| Protected Attributes inherited from XC::MeshCompRecorder | |
| double | deltaT |
| double | nextTimeStampToRecord |
| Protected Attributes inherited from XC::HandlerRecorder | |
| DataOutputHandler * | theHandler |
| Output handler (TO DEPRECATE). | |
| bool | initializationDone |
| bool | echoTimeFlag |
| Protected Attributes inherited from XC::DomainRecorderBase | |
| Domain * | theDomain |
A EnvelopeRecorder is used to record the envelop of specified DOF responses at a collection of nodes over an analysis. (between commitTag of 0 and last commitTag).
