Specifies a tolerace for the displacement increment norm to be used on each iteration. More...
#include <CTestNormDispIncr.h>
Public Member Functions | |
| CTestNormDispIncr (EntCmd *owr=nullptr) | |
| CTestNormDispIncr (EntCmd *owr, double tol, int maxNumIter, int printFlag, int normType=2) | |
| ConvergenceTest * | getCopy (void) const |
| Virtual constructor. | |
| virtual std::string | getStatusMsg (const int &flag=1) const |
| Returns a message showing the values of the principal parameters. | |
| int | test (void) |
 Public Member Functions inherited from XC::ConvergenceTestTol | |
| ConvergenceTestTol (EntCmd *owr, int classTag) | |
| Constructor. | |
| ConvergenceTestTol (EntCmd *owr, int classTag, double tol, int maxNumIter, int printFlag, int normType, int sz_norms=1) | |
| Constructor. | |
| void | setTolerance (double newTol) |
| double | getTolerance (void) const |
| int | sendSelf (CommParameters &) |
| int | recvSelf (const CommParameters &) |
| std::string | getRatioMessage (const std::string &) const |
| Display current ratio and tolerance. | |
| std::string | getDispIncrMessage (void) const |
| Display current displacement increment and tolerance. | |
| std::string | getUnbalanceMessage (void) const |
| Display current unbalance and tolerance. | |
| std::string | getEnergyProductMessage (void) const |
| Display current energy product and tolerance. | |
| Public Member Functions inherited from XC::ConvergenceTest | |
| ConvergenceTest (EntCmd *owr, int classTag) | |
| ConvergenceTest (EntCmd *owr, int clasTag, int maxIter, int prtFlg, int normType, int sz_norms=1) | |
| virtual ConvergenceTest * | getCopy (int iterations) const |
| virtual int | start (void) |
| int | getMaxNumIter (void) const |
| void | setMaxNumIter (const int &) |
| int | getCurrentIter (void) const |
| void | setCurrentIter (const int &) |
| int | getPrintFlag (void) const |
| void | setPrintFlag (const int &) |
| int | getNormType (void) const |
| void | setNormType (const int &) |
| virtual int | getNumTests (void) const |
| virtual int | getMaxNumTests (void) const |
| virtual double | getRatioNumToMax (void) const |
| virtual const Vector & | getNorms (void) const |
| std::string | getTestIterationMessage (void) const |
| Returns a string with the name of the class and the iteration number. | |
| std::string | getFailedToConvergeMessage (void) const |
| Returns a string with the proper failed to converge message. | |
| std::string | getDeltaXRMessage (void) const |
| Returns a string with the values of x and b vectors. | |
| std::string | getDeltaXRNormsMessage (void) const |
| Returns a string with the values of x and b vector norms. | |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Additional Inherited Members | |
| Protected Member Functions inherited from XC::ConvergenceTestTol | |
| int | sendData (CommParameters &) |
| Send object members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receives object members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::ConvergenceTest | |
| bool | hasLinearSOE (void) const |
| Returns true ifpuede acceder al system of equations. | |
| LinearSOE * | getLinearSOEPtr (void) |
| Returns a pointer to the system of equations. | |
| const LinearSOE * | getLinearSOEPtr (void) const |
| Returns a const pointer to the system of equations. | |
| const Vector & | getX (void) const |
| Returns the vector de incógnitas. | |
| double | getNormX (void) const |
| Return the norma del vector de incógnitas. | |
| const Vector & | getB (void) const |
| Returns the vector de términos independientes. | |
| double | getNormB (void) const |
| Return the norma del vector de términos independientes. | |
| double | getEnergyProduct (void) const |
| Returns the the energy increment, which is 0.5 times the absolute value of the product of the rhs and the solution vector of the LinearSOE: |0.5*(x ^ b)|. | |
| int | sendData (CommParameters &) |
| Send object members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receives object members through the channel being passed as parameter. | |
| Protected Attributes inherited from XC::ConvergenceTestTol | |
| double | tol |
| the tol on the energy used to test for convergence | |
| Protected Attributes inherited from XC::ConvergenceTest | |
| int | currentIter |
| number of times test() has been invokes since last start() | |
| int | maxNumIter |
| max number of iterations | |
| int | printFlag |
| a flag indicating if to print on test | |
| int | nType |
| type of norm to use (1-norm, 2-norm, p-norm, max-norm) | |
| Vector | norms |
| vector to hold the norms | |
| double | lastRatio |
| Last calculated ratio (if any). | |
| double | calculatedNormX |
| Last calculated |x|. | |
| double | calculatedNormB |
| Last calculated |b|. | |
| double | calculatedEnergyProduct |
| Last calculated |0.5*(x ^ b)|. | |
Specifies a tolerace for the displacement increment norm to be used on each iteration.
