XC Open source finite element analysis program
|
Set of objecst in a row. More...
#include <SetFilaI.h>
Public Types | |
| typedef TritrizPtrNod::var_ref_fila_i | tfilanod |
| typedef TritrizPtrElem::var_ref_fila_i | tfilaelem |
 Public Types inherited from XC::SetFila< TritrizPtrNod::var_ref_fila_i, TritrizPtrElem::var_ref_fila_i > | |
| typedef TritrizPtrNod::var_ref_fila_i::reference | reference_nod |
| typedef TritrizPtrNod::var_ref_fila_i::const_reference | const_reference_nod |
| typedef TritrizPtrElem::var_ref_fila_i::reference | reference_elem |
| typedef TritrizPtrElem::var_ref_fila_i::const_reference | const_reference_elem |
Public Member Functions | |
| SetFilaI (EntMdlr &e, const size_t &f=1, const size_t &c=1, const std::string &nmb="", Preprocessor *preprocessor=nullptr) | |
| SetFilaI (EntMdlr &e, const RangoIndice &rango_capas, const size_t &f, const size_t &c, const std::string &nmb="", Preprocessor *preprocessor=nullptr) | |
| Public Member Functions inherited from XC::SetFila< TritrizPtrNod::var_ref_fila_i, TritrizPtrElem::var_ref_fila_i > | |
| SetFila (const TritrizPtrNod::var_ref_fila_i &fn, const TritrizPtrElem::var_ref_fila_i &fe, const std::string &nmb="", Preprocessor *preprocessor=nullptr) | |
| SetFila (const SetFila &otro) | |
| SetFila & | operator= (const SetFila &otro) |
| Assignment operator. | |
| virtual SetEstruct * | getCopy (void) const |
| Virtual constructor. | |
| reference_nod | Nodo (const size_t &i) |
| const reference_nod | Nodo (const size_t &i) const |
| reference_elem | Element (const size_t &i) |
| const reference_elem | Element (const size_t &i) const |
| RangoTritriz | RangoNodos (void) const |
| RangoTritriz | ElementRange (void) const |
| virtual size_t | getNumNodeLayers (void) const |
| virtual size_t | getNumNodeRows (void) const |
| virtual size_t | getNumNodeColumns (void) const |
| virtual size_t | getNumElementLayers (void) const |
| virtual size_t | getNumElementRows (void) const |
| virtual size_t | getNumElementColumns (void) const |
| virtual XC::Node * | GetNodo (const size_t &i=1, const size_t &j=1, const size_t &k=1) |
| virtual const XC::Node * | GetNodo (const size_t &i=1, const size_t &j=1, const size_t &k=1) const |
| virtual XC::Element * | getElement (const size_t &i=1, const size_t &j=1, const size_t &k=1) |
| virtual const XC::Element * | getElement (const size_t &i=1, const size_t &j=1, const size_t &k=1) const |
| Public Member Functions inherited from XC::SetEstruct | |
| SetEstruct (const std::string &nmb="", Preprocessor *preprocessor=nullptr) | |
| Constructor. | |
| SetEstruct (const SetEstruct &otro) | |
| Copy constructor. | |
| SetEstruct & | operator= (const SetEstruct &otro) |
| Assignment operator. | |
| size_t | getNumberOfNodes (void) const |
| size_t | getNumberOfElements (void) const |
| bool | In (const Node *) const |
| Returns true if the nodo belongs to the set. | |
| bool | In (const Element *) const |
| Returns true if the element belongs to the set. | |
| bool | EsFilaI (void) const |
| Returns true if only the I index varies. | |
| bool | EsFilaJ (void) const |
| Returns true if only the J index varies. | |
| bool | EsFilaK (void) const |
| Returns true if only the K index varies. | |
| bool | EsCapaICte (void) const |
| Returns true if only J and K indices varies. | |
| bool | EsCapaJCte (void) const |
| Returns true if only J and K indices varies. | |
| bool | EsCapaKCte (void) const |
| Returns true if only I and J indices varies. | |
| size_t | Dimension (void) const |
| Return the dimension of the range (0,1,2 or 3). Zero if the range is empty, 1 if there is more than one layer, 2 if there are more than one row and three if there are more than one column. | |
| std::string | GetStrTipo (void) const |
| Returns the set type filaI, filaJ, filaK, capaICte,... | |
| Node * | getNodeI (const size_t &i) |
| Node * | getNodeIJ (const size_t &i, const size_t &j) |
| Node * | getNodeIJK (const size_t &i, const size_t &j, const size_t &k) |
| Element * | getElementI (const size_t &i) |
| Element * | getElementIJ (const size_t &i, const size_t &j) |
| Element * | getElementIJK (const size_t &i, const size_t &j, const size_t &k) |
| std::set< int > | getNodeTags (void) const |
| Returns the tags of the nodes. | |
| boost::python::list | getNodes (void) |
| std::set< int > | getElementTags (void) const |
| Returns the tags of the elements. | |
| boost::python::list | getElements (void) |
| ElementEdges | getElementEdges (void) |
| Returns the element edges with both end nodes belong to the nodes of the set. | |
| Public Member Functions inherited from XC::SetBase | |
| SetBase (const std::string &nmb="", Preprocessor *preprocessor=nullptr) | |
| Constructor. | |
| virtual void | genMesh (meshing_dir dm) |
| Generates a finite element mesh from the set components. | |
| virtual void | fix (const SFreedom_Constraint &) |
| Impone desplazamiento nulo en los nodos de this set. | |
| const ID & | getIdNodeTags (void) const |
| Returns the tags of the nodes en un vector de enteros. | |
| const ID & | getIdElementTags (void) const |
| Returns the tags of the elements en un vector de enteros. | |
| virtual bool | In (const Pnt *) const |
| Returns true if the point belongs to the set. | |
| virtual bool | In (const Edge *) const |
| Returns true if the edge belongs to the set. | |
| virtual bool | In (const Face *) const |
| Returns true if the surface belongs to the set. | |
| virtual bool | In (const Body *) const |
| Returns true if the body belongs to the set. | |
| virtual bool | In (const UniformGrid *) const |
| Returns true if the «uniform grid» belongs to the set. | |
| void | resetTributarias (void) const |
| Reset tributary areas (or lengths, or volumes) for the nodes that are connected to the set elements. | |
| void | calculaLongsTributarias (bool initialGeometry=true) const |
| Calcula las longitudes tributarias correspondientes a cada nodo of the elements of the set. | |
| void | calculaAreasTributarias (bool initialGeometry=true) const |
| Calcula las áreas tributarias correspondientes a cada nodo of the elements of the set. | |
| void | calculaVolsTributarios (bool initialGeometry=true) const |
| Calcula los volúmenes tributarios correspondientes a cada nodo of the elements of the set. | |
| Public Member Functions inherited from XC::EntMdlrBase | |
| EntMdlrBase (const std::string &nmb="", Preprocessor *preprocessor=nullptr) | |
| Constructor. | |
| EntMdlrBase (const EntMdlrBase &otro) | |
| Copy constructor. | |
| EntMdlrBase & | operator= (const EntMdlrBase &otro) |
| Assignment operator. | |
| const Preprocessor * | GetPreprocessor (void) const |
| Preprocessor * | GetPreprocessor (void) |
| size_t | GetTag (void) const |
| Return the object identifier in the model (tag). | |
| Pnt * | BuscaPnt (const size_t &) |
| Return a pointer to the point identified by the tag being passed as parameter. | |
| const Pnt * | BuscaPnt (const size_t &) const |
| Return a const pointer to the point identified by the tag being passed as parameter. | |
| Edge * | BuscaEdge (const size_t &) |
| Return a pointer to the edge identified by the tag being passed as parameter. | |
| const Edge * | BuscaEdge (const size_t &) const |
| Return a pointer to the edge identified by the tag being passed as parameter. | |
| Face * | BuscaFace (const size_t &) |
| Return a pointer to the face identified by the tag being passed as parameter. | |
| const Face * | BuscaFace (const size_t &) const |
| Returns a pointer to the face identified by the tag being passed as parameter. | |
| virtual int | sendSelf (CommParameters &) |
| Send objects through the channel being passed as parameter. | |
| virtual int | recvSelf (const CommParameters &) |
| Receive objects through the channel being passed as parameter. | |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Additional Inherited Members | |
| Protected Member Functions inherited from XC::SetEstruct | |
| void | add_elements (const TritrizPtrElem &) |
| Adds to the model the elements being passed as parameters. | |
| NodePtrSet | getNodePtrSet (void) |
| Returns the pointers to the set nodes. | |
| Protected Member Functions inherited from XC::EntMdlrBase | |
| const Preprocessor * | get_preprocessor (void) const |
| Return a pointer to the preprocessor. | |
| Preprocessor * | get_preprocessor (void) |
| Return a pointer to the preprocessor. | |
| bool | check_preprocessor (void) const |
| Check for preprocessor. | |
| int | sendIdsEtiquetas (const int &, const int &, CommParameters &) |
| Send labels through the channel being passed as parameter. | |
| int | recvIdsEtiquetas (const int &, const int &, const CommParameters &) |
| Receive labels through the channel being passed as parameter. | |
| int | sendData (CommParameters &) |
| Send members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receive members through the channel being passed as parameter. | |
| Protected Attributes inherited from XC::EntMdlrBase | |
| LabelContainer | labels |
| Label container. | |
Set of objecst in a row.
An SetFilaI objects contains zero or more:
