XC Open source finite element analysis program
|
Time-dependent function that linear interpolates the load factor using user specified control points provided in a vector object. the points in the vector are given at time points specified in another vector. More...
#include <PathTimeSeries.h>
Public Member Functions | |
| PathTimeSeries (void) | |
| Default constructor. | |
| PathTimeSeries (const Vector &thePath, const Vector &theTime, double cfactor=1.0) | |
| Constructor. | |
| PathTimeSeries (const std::string &fileNamePath, const std::string &fileNameTime, double cfactor=1.0) | |
| Constructor. | |
| PathTimeSeries (const std::string &fileName, double cfactor=1.0) | |
| Constructor. | |
| TimeSeries * | getCopy (void) const |
| double | getFactor (double pseudoTime) const |
| Returns the valor correspondiente al instante being passed as parameter. | |
| double | getDuration (void) const |
| Returns series duration. | |
| double | getTimeIncr (double pseudoTime) const |
| Vector | getTime (void) const |
| void | setTime (const Vector &d) |
| int | getCurrentTimeLoc (void) const |
| void | setCurrentTimeLoc (const int &d) |
| void | readFromFile (const std::string &fileName) |
| Lee el path desde archivo. | |
| void | readFromFiles (const std::string &filePathName, const std::string &fileTimeName) |
| Lee el path desde DOS archivos. | |
| int | sendSelf (CommParameters &) |
| Sends object through the channel being passed as parameter. | |
| int | recvSelf (const CommParameters &) |
| Receives object through the channel being passed as parameter. | |
| void | Print (std::ostream &s, int flag=0) const |
| Imprime el objeto. | |
 Public Member Functions inherited from XC::PathSeriesBase | |
| PathSeriesBase (int classTag, const double &cfactor=1.0) | |
| Constructor. | |
| PathSeriesBase (int classTag, const Vector &thePath, const double &cfactor=1.0) | |
| Constructor. | |
| size_t | getNumDataPoints (void) const |
| Returns the número de puntos que definen el path. | |
| size_t | getNumDataPointsOnFile (const std::string &) const |
| Returns the number of data en on the file with the name being passed as parameter. | |
| double | getPeakFactor (void) const |
| Returns the peak value of the factor. | |
| Vector | getPath (void) const |
| void | setPath (const Vector &d) |
| int | getLastSendCommitTag (void) const |
| void | setLastSendCommitTag (const int &d) |
| Public Member Functions inherited from XC::CFactorSeries | |
| CFactorSeries (int classTag, double cFactor=1.0) | |
| Constructor. | |
| void | setFactor (const double &d) |
| Public Member Functions inherited from XC::TimeSeries | |
| TimeSeries (int classTag) | |
| Constructor. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual double | getFactorSensitivity (double pseudoTime) |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Protected Member Functions | |
| int | sendData (CommParameters &cp) |
| Send members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receives members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::PathSeriesBase | |
| int | sendData (CommParameters &cp) |
| Send members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receives members through the channel being passed as parameter. | |
| Protected Member Functions inherited from XC::CFactorSeries | |
| DbTagData & | getDbTagData (void) const |
| Returns a vector para almacenar los dbTags de los miembros de la clase. | |
| int | sendData (CommParameters &cp) |
| Send object members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &cp) |
| Receives object members through the channel being passed as parameter. | |
Additional Inherited Members | |
| Static Protected Member Functions inherited from XC::PathSeriesBase | |
| static size_t | load_vector_from_file (Vector &v, std::istream &is) |
| Lee desde archivo. | |
| Protected Attributes inherited from XC::PathSeriesBase | |
| Vector | thePath |
| vector containg the data points | |
| int | lastSendCommitTag |
| Protected Attributes inherited from XC::CFactorSeries | |
| double | cFactor |
Time-dependent function that linear interpolates the load factor using user specified control points provided in a vector object. the points in the vector are given at time points specified in another vector.
