XC Open source finite element analysis program
|
Base class for integration on beam elements. More...
#include <BeamIntegration.h>
Public Member Functions | |
| BeamIntegration (int classTag) | |
| virtual void | getSectionLocations (int nIP, double L, double *xi) const =0 |
| virtual void | getSectionWeights (int nIP, double L, double *wt) const =0 |
| const Matrix & | getIntegrPointCoords (int nIP, double L) const |
| Returns the coordenadas normalizadas (entre 0 y 1). | |
| const Matrix & | getIntegrPointNaturalCoords (int nIP, double L) const |
| Returns the coordenadas naturales (entre -1 y 1) a partir de las normalizadas. | |
| const Matrix & | getIntegrPointLocalCoords (int nIP, double L) const |
| Returns the coordenadas locales (entre 0 y L) a partir de las normalizadas. | |
| const Matrix & | getIntegrPointNaturalCoords (int nIP, const CrdTransf &trf) const |
| Returns a matrix with the natural coordinates for each integration point. | |
| const Matrix & | getIntegrPointNormalizedCoords (int nIP, const CrdTransf &trf) const |
| Returns a matrix with the normalized coordinates for each integration point. | |
| const Matrix & | getIntegrPointLocalCoords (int nIP, const CrdTransf &trf) const |
| Returns a matrix with the local coordinates for each integration point. | |
| const Matrix & | getIntegrPointGlobalCoords (int nIP, const CrdTransf &trf) const |
| Returns a matrix with the global coordinates for each integration point. | |
| const Vector & | evalInIntegrPoints (const ExprAlgebra &expr, int nIP, const CrdTransf &trf) const |
| Returns the values of the expresion being pased as parameter on each integration point. | |
| double | getIntegral (const ExprAlgebra &expr, int nIP, const CrdTransf &trf) const |
| Returns the integral of the expresion. | |
| virtual void | addElasticDeformations (ElementalLoad *theLoad, double loadFactor, double L, FVector &v0) |
| virtual int | addElasticFlexibility (double L, Matrix &fe) |
| virtual double | getTangentDriftI (double L, double LI, double q2, double q3, bool yAxis=false) |
| virtual double | getTangentDriftJ (double L, double LI, double q2, double q3, bool yAxis=false) |
| virtual BeamIntegration * | getCopy (void) const =0 |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual void | getLocationsDeriv (int nIP, double L, double dLdh, double *dptsdh) |
| virtual void | getWeightsDeriv (int nIP, double L, double dLdh, double *dwtsdh) |
| virtual int | addElasticFlexDeriv (double L, Matrix &dfedh, double dLdh=0.0) |
| virtual void | Print (std::ostream &s, int flag=0)=0 |
 Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | sendSelf (CommParameters &)=0 |
| virtual int | recvSelf (const CommParameters &)=0 |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Base class for integration on beam elements.
