| VectorReinfBar (const size_t &sz=0) |
| | Constructor.
|
| |
|
| VectorReinfBar (const VectorReinfBar &otro) |
| | Copy constructor.
|
| |
|
VectorReinfBar & | operator= (const VectorReinfBar &otro) |
| | Assignment operator.
|
| |
|
| ~VectorReinfBar (void) |
| | Destructor.
|
| |
|
size_t | size (void) const |
| |
|
size_t | empty (void) const |
| |
|
iterator | begin (void) |
| |
|
iterator | end (void) |
| |
|
const_iterator | begin (void) const |
| |
|
const_iterator | end (void) const |
| |
|
double | getAreaGrossSection (void) const |
| | Return gross area of rebars.
|
| |
|
Vector | getCdgGrossSection (void) const |
| | Returns gross section centroid.
|
| |
|
double | getIyGrossSection (void) const |
| | Inertia of the gross section about an axis parallel to y through his center of gravity.
|
| |
|
double | getIzGrossSection (void) const |
| | Inertia of the gross section about an axis parallel to z through his center of gravity.
|
| |
|
double | getPyzGrossSection (void) const |
| | Product of inertia of the gross section about y and z axis through his center of gravity.
|
| |
|
double | getAreaHomogenizedSection (const double &E0) const |
| | Returns the homogenized area de las regiones.
|
| |
|
Vector | getCdgHomogenizedSection (const double &E0) const |
| |
| double | getIyHomogenizedSection (const double &E0) const |
| | Returns homogenized moment of inertia of the cross-section with respecto to the axis parallel to y passing through the centroid. More...
|
| |
| double | getIzHomogenizedSection (const double &E0) const |
| | Returns homogenized moment of inertia of the cross-section with respecto to the axis parallel to z passing through the centroid. More...
|
| |
| double | getPyzHomogenizedSection (const double &E0) const |
| | Returns homogenized product of inertia of the cross-section with respecto to the axis parallel to y and z passing through the centroid. More...
|
| |
|
void | resize (const size_t sz) |
| | Resizes vector.
|
| |
|
void | put (const size_t i, const ReinfBar &c) |
| |
|
const_reference | operator[] (const size_t i) const |
| |
|
void | Print (std::ostream &s) const |
| |
|
| SeccionInerte (EntCmd *owr=nullptr) |
| |
|
double | getIxGrossSection (void) const |
| | Inertia of the gross section about an axis parallel to x through his center of gravity.
|
| |
|
double | getTheta_pGrossSection (void) const |
| | Agle of the principal axis of inertia of the gross section with respect of current axis.
|
| |
|
Vector | getDirEjeI_aGrossSection (void) const |
| | Direction of a principal axis of inertia of the gross section with respect of current axis.
|
| |
|
Vector | getDirEjeI_bGrossSection (void) const |
| | Direction of the other principal axis of inertia of the gross section with respect of current axis.
|
| |
|
double | getI1GrossSection (void) const |
| | Major principal moment of inertia of the gross section.
|
| |
|
double | getI2GrossSection (void) const |
| | Minor principal moment of inertia of the gross section.
|
| |
|
PrincipalAxesOfInertia2D | getEjesInerciaGrossSection (void) const |
| | Principal axis of inertia of the gross section.
|
| |
|
Vector2d | getVDirEje1GrossSection (void) const |
| | Direction of the major principal axis of inertia of the gross section.
|
| |
|
Vector2d | getVDirStrongAxisGrossSection (void) const |
| | Direction of the major principal axis of inertia of the gross section.
|
| |
|
Vector2d | getVDirEje2GrossSection (void) const |
| | Direction of the minor principal axis of inertia of the gross section.
|
| |
|
Vector2d | getVDirWeakAxisGrossSection (void) const |
| | Direction of the minor principal axis of inertia of the gross section.
|
| |
|
double | getIGrossSection (const unsigned short int &, const unsigned short int &) const |
| | Return the i,j component of the tensor of inertia computed with respect to centroid.
|
| |
|
double | getIGrossSection (const unsigned short int &, const unsigned short int &, const Pos2d &) const |
| | Return the i,j component of the tensor of inertia computed with respect to the point "o".
|
| |
|
double | getIGrossSection (const Pos2d &, const Vector &) const |
| | Returns the moment of inertia with respect to the axis that passes through O with the direction of e.
|
| |
|
double | getIGrossSection (const Recta2d &) const |
| | Returns the moment of inertia respecto a la recta being passed as parameter.
|
| |
|
double | getIOGrossSection (const Pos2d &) const |
| | Returns the momento polar de inercia with respect to the point o.
|
| |
|
Matrix | getIGrossSection (void) const |
| | Returns the tensor of inertia computed with respect to the object centroid.
|
| |
|
Matrix | getIGrossSection (const Pos2d &) const |
| | Returns the tensor of inertia respector al punto o.
|
| |
| double | getIxHomogenizedSection (const double &) const |
| | Inertia of the homogenized section about an axis parallel to x through his center of gravity. More...
|
| |
|
double | getTheta_pHomogenizedSection (void) const |
| | Agle of the principal axis of inertia of the homogenized section with respect of current axis.
|
| |
| Vector | getDirEjeI_aHomogenizedSection (void) const |
| | Direction of a principal axis of inertia of the homogenized section with respect of current axis. More...
|
| |
| Vector | getDirEjeI_bHomogenizedSection (void) const |
| | Direction of the other axis of inertia of the homogenized section with respect of current axis. More...
|
| |
|
double | getI1HomogenizedSection (const double &) const |
| | Major principal moment of inertia of the homogenized section.
|
| |
|
double | getI2HomogenizedSection (const double &) const |
| | Minor principal moment of inertia of the homogenized section.
|
| |
|
PrincipalAxesOfInertia2D | getEjesInerciaHomogenizedSection (const double &) const |
| | Principal axis of inertia of the homogenized section.
|
| |
|
Vector2d | getVDirEje1HomogenizedSection (const double &) const |
| | Direction of the major principal axis of inertia of the homogenized section.
|
| |
|
Vector2d | getVDirStrongAxisHomogenizedSection (const double &) const |
| | Direction of the major principal axis of inertia of the homogenized section.
|
| |
|
Vector2d | getVDirEje2HomogenizedSection (const double &) const |
| | Direction of the minor principal axis of inertia of the homogenized section.
|
| |
|
Vector2d | getVDirWeakAxisHomogenizedSection (const double &) const |
| | Direction of the minor principal axis of inertia of the homogenized section.
|
| |
|
double | getIHomogenizedSection (const double &, const unsigned short int &, const unsigned short int &) const |
| | tensor of inertia (i,j) component of the homogenized section.
|
| |
|
double | getIHomogenizedSection (const double &, const unsigned short int &, const unsigned short int &, const Pos2d &) const |
| | Return the i,j component of the tensor of inertia computed with respect to the point "o".
|
| |
|
double | getIHomogenizedSection (const double &, const Pos2d &, const Vector &) const |
| | Returns the moment of inertia with respect to the axis that passes through O with the direction of e.
|
| |
|
double | getIHomogenizedSection (const double &, const Recta2d &) const |
| | Returns the moment of inertia respecto a la recta being passed as parameter.
|
| |
|
double | getIOHomogenizedSection (const double &, const Pos2d &) const |
| | Returns the momento polar de inercia with respect to the point o.
|
| |
|
Matrix | getIHomogenizedSection (const double &) const |
| | Returns the tensor of inertia computed with respect to the object centroid.
|
| |
|
Matrix | getIHomogenizedSection (const double &, const Pos2d &) const |
| | Returns the tensor of inertia respector al punto o.
|
| |
|
CrossSectionProperties3d | getCrossSectionProperties3d (const CrossSectionProperties3d &) const |
| |
|
CrossSectionProperties2d | getCrossSectionProperties2d (const CrossSectionProperties2d &) const |
| |
Vector de barras de armadura.
Public Member Functions inherited from XC::SeccionInerte
