Region of a section that corresponds with a material. More...
#include <RegionSecc.h>
Public Member Functions | |
| RegionSecc (Material *) | |
| virtual int | getNumCells (void) const =0 |
| Returns the number of cells of the region. | |
| virtual const VectorCells & | getCells (void) const =0 |
| Returns the contenedor de celdas. | |
| virtual RegionSecc * | getCopy (void) const =0 |
| Returns a copy of the region. | |
| virtual Poligono2d | getPoligono (void) const |
| RgSccPoligono | Interseccion (const Semiplano2d &sp) const |
| const Vector & | Cdg (void) const |
| Returns the coordenadas of the centro de gravedad. | |
| double | Longitud (void) const |
| Returns the region contour lenght. | |
| double | Area (void) const |
| Returns the region area. | |
| double | Iy (void) const |
| Returns the moment of inertia with respect to the axis paralelo al y por el centroid. | |
| double | Iz (void) const |
| Returns the moment of inertia with respect to the axis paralelo al z por el centroid. | |
| double | Pyz (void) const |
| Returns the producto de inercia respecto a los ejes paralelos por el centroid. | |
| double | Ix (void) const |
| Returns the moment of inertia polar with respect to centroid en ejes locales. | |
| double | Theta_p (void) const |
| Returns the ángulo que define un principal axis of inertia. | |
| const Vector & | DirEjeI_a (void) const |
| Return the direction of a principal axis of inertia (we don't know yet if it's the major one or the minor one). | |
| const Vector & | DirEjeI_b (void) const |
| Return the direction of the other (with respect to DirEjeI_a) principal axis of inertia (we don't know yet if it's the major one or the minor one). | |
| double | getI1 (void) const |
| Returns the principal major axis of inertia. | |
| double | getI2 (void) const |
| Returns the principal minor axis of inertia. | |
| double | getI (const unsigned short int &i, const unsigned short int &j) const |
| Return the i,j component of the tensor of inertia computed with respect to centroid. | |
| double | getI (const unsigned short int i, const unsigned short int j, const Pos2d &o) const |
| Return the i,j component of the tensor of inertia computed with respecto to the point "o". | |
| double | getI (const Pos2d &O, const Vector &e) const |
| Returns the moment of inertia with respect to the axis that passes through O with the direction of e. | |
| double | getIO (const Pos2d &o) |
| Returns the momento polar de inercia with respect to the point o. | |
| Matrix & | getI (void) const |
| Returns the tensor of inertia computed with respect to the object centroid. | |
| Matrix & | getI (const Pos2d &o) const |
| Returns the tensor of inertia respector al punto o. | |
| virtual void | Print (std::ostream &s, int flag=0) const =0 |
 Public Member Functions inherited from XC::DiscretBase | |
| DiscretBase (Material *mat) | |
| virtual double | getMaxY (void) const =0 |
| virtual double | getMaxZ (void) const =0 |
| virtual double | getMinY (void) const =0 |
| virtual double | getMinZ (void) const =0 |
| void | setMaterialPtr (Material *mat) |
| Material * | getMaterialPtr (void) const |
Protected Attributes | |
| VectorCells | cells |
Friends | |
| std::ostream & | operator<< (std::ostream &s, const RegionSecc &rg_scc) |
Region of a section that corresponds with a material.
