Point container. More...
#include <MapPuntos.h>
Public Member Functions | |
| MapPuntos (Cad *cad=nullptr) | |
| Constructor. | |
| Vector3d | getVector (const Indice &i, const Indice &j) const |
| Returns the vector defined by the points which indices are being passed as parameters. | |
| Recta3d | getRecta (const Indice &i, const Indice &j) const |
| Return the line defined by the points which indices are being passed as parameters. | |
| Plano3d | getPlano (const Indice &i, const Indice &j, const Indice &k) const |
| Returns the plane defined by the points which indices are being passed as parameters. | |
| Pnt * | New (void) |
| Creates a new point. | |
| Pnt * | New (const Pos3d &) |
| Creates a new point at the position being passed as parameter. | |
| Pnt * | New (const size_t &, const Pos3d &) |
| Creates a new point with the tag being passed as parameter. | |
| Pnt * | Copia (const Pnt *, const Vector3d &v) |
| Creates a new point, copia del being passed as parameter con el nombre que le toca según el valor del tag. Las coordenadas del new point serán las que resulten de sumar a las del primitivo el vector being passed as parameter. | |
| void | Copia (const std::vector< MapPuntos::Indice > &) |
| Crea copias de los puntos cuyos identificadores being passed as parameters. | |
| void | Transforma (const TrfGeom &trf, const std::vector< MapPuntos::Indice > &) |
| Applies the transformation to the points identified by the indices being passed as parameter. | |
| double | Dist (const Indice &i, const Indice &j) const |
| Return the distancia entre los puntos cuyos identificadores being passed as parameters. | |
 Public Member Functions inherited from XC::MapEnt< Pnt > | |
| MapEnt (Cad *cad=nullptr) | |
| Constructor. | |
| Pnt * | getNearest (const Pos3d &p) |
| Returns the object closest to the position being passed as parameter. | |
| const Pnt * | getNearest (const Pos3d &p) const |
| Returns the object closest to the position being passed as parameter. | |
| void | numera (void) |
| Set indices to the objects to allow its use in VTK. | |
| Public Member Functions inherited from XC::MapCadMember< Pnt > | |
| MapCadMember (Cad *cad=nullptr) | |
| Constructor. | |
| Pnt * | busca (const Indice &) |
| Return a pointer to the geometry entity whose identifier is passed as parameter. | |
| const Pnt * | busca (const Indice &) const |
| Return a pointer to the entity whose identifier is passed as parameter. | |
| bool | existe (const Indice &) const |
| Return true if the entity already exists. | |
| Pnt * | get (const Indice &) |
| Return the entity with tag iEnt. | |
| boost::python::list | getKeys (void) const |
| Return the container's keys. | |
| void | clearAll (void) |
| Erase all the entities. | |
| Public Member Functions inherited from XC::MapCadMemberBase | |
| MapCadMemberBase (Cad *cad=nullptr) | |
| Default identifier for new point. More... | |
| const Cad * | getCad (void) const |
| Return a pointer to Cad. | |
| Cad * | getCad (void) |
| Return a pointer to Cad. | |
| const Preprocessor * | getPreprocessor (void) const |
| Return a pointer to preprocessor. | |
| Preprocessor * | getPreprocessor (void) |
| Return a pointer to preprocessor. | |
| size_t | getTag (void) const |
| void | setTag (const size_t &t) |
Protected Member Functions | |
| Pnt * | Crea (void) |
| Creates a new point. | |
Additional Inherited Members | |
| Public Types inherited from XC::MapEnt< Pnt > | |
| typedef MapCadMember< Pnt >::iterator | iterator |
| typedef MapCadMember< Pnt >::const_iterator | const_iterator |
| Public Types inherited from XC::MapCadMember< Pnt > | |
| typedef std::map< Indice, Pnt * > | map_base |
| typedef std::pair< Indice, Pnt * > | pair |
| typedef map_base::iterator | iterator |
| typedef map_base::const_iterator | const_iterator |
| Public Types inherited from XC::MapCadMemberBase | |
| typedef size_t | Indice |
| Protected Attributes inherited from XC::MapCadMemberBase | |
| Indice | tag |
Point container.
